SPECIFICATIONS
Measuring principle:Potentiometric
Application:Long-term monitoring, processes with little change；Water and wastewater treatment
Characteristic:Analog, digital pH electrodes for standard applications in process and environmental technology；Dirt-repellent PTFE diaphragm, built-in temperature sensor
Measurement range:pH 0 to 14
Measuring principle:Gel compact electrode with PTFE ring-diaphragm
Design:All shaft lengths with temperature sensor；Advanced gel technology；Digital electrode with Memosens technology
Material:Glass and PTFE
Dimension:Diameter: 12 mm (0.47 inch)；Shaft length: 120, 225 and 360 mm(4.72, 8.86 and 14.17 inch)
Process temperature:0 to 135 °C (32 to 275 °F)
Process pressure:1 to 17 bar (15 to 246 psi)
Temperature sensor:NTC 30k
Ex certification:ATEX, FM, CSA, NEPSI
Connection:Inductive, digital connection head with Memosens technology
Ingress protection:IP68
Additional certifications:Also available as SIL version
Field of application
Orbisint CPS11D is not the latest Memosens generation and will be phased out soon. To get information on the new Memosens CPS11E sensor with extended functionality, click here.Orbisint CPS11D is the digital all-rounder for process and environmental technology. It measures reliably even in highly alkaline media or hazardous areas. Designed for low maintenance and a long operating life, the electrode offers you best value for money.
Long-term monitoring and limit monitoring of processes with stable process conditions: - Chemical industry - Paper industry - Power plants (e.g. flue gas washers, boiler feed water) - Incineration plants Water treatment: - Drinking water - Cooling water - Well water With ATEX, FM, CSA approval for use in hazardous areas. Robust electrode with long poison diffusion path, requires low maintenance due to large, dirt-repellent PTFE ring diaphragm
Suitable for harsh applications: Process glass for highly alkaline media and pressure-stable up to 16 bar (232 psi)
Optional salt ring for low conductivity applications such as boiler feed water and water for injection
Maximum process safety through non-contact, inductive signal transmission
Enables predictive maintenance due to storage of sensor and process-specific data
Reduced operating costs thanks to minimized process downtime and extended sensor lifetime
